Pick up Element
1/3" HR color CCD image sensor
Number of Pixel
771(H) x 492(V) <NTSC> / 753(H) x 582(V) <PAL>
Resolution
520 TV lines
Minimum illumination
0.3 Lux / F2.0, 0 Lux (IR ON)
IR LED
21 units
IR Effective Range
Up to 15 meters
S/N Ratio
More than 48dB (AGC off)
Electronic Shutter
1/60 (1/50) to 1/100,000 sec.
Lens
f6.0mm / F2.0
Lens Angle
54°
IRIS Mode
AES
White Balance
ATW
Video Output
1.0Vp-p composite, 75Ω
Power Source (±10%)
DC12V
Current Consumption (0%) ±1
90mA (IR Off); 240mA (IR On)
Dimensions (mm)**
94(Ø) × 73(H)
Weight (g)
131
