Video System
NTSC / PAL (auto switchable)
Video Compression Format
H.264
Video Input
(Composite video signal 1 Vp-p 75Ω BNC)
8 channels
Video Output (BNC)
Main Monitor Output: for stable display
Audio Input / Output
4 audio inputs, 1 audio output (Mono)
Maximum Recording Rate
Frame
704×480 pixels with 60 IPS / 704×576 pixels with 50 IPS
CIF
352×240 pixels with 240 IPS / 352×288 pixels with 200 IPS
Image Quality Setting
SUPER BEST / BEST / HIGH / NORMAL
Hard Disk Storage
Accommodates 2 SATA HDDs (1 HDD capacity up to 2TB)
Quick Search
Time / Motion / Alarm search mode
SATA Interface
Built-in
VGA Interface
Built-in (Output resolution up to 1600 x 1200)
Recording Mode
Manual / Timer / Motion / Alarm / Remote
Multiplex Operation
Live display / record / playback / backup / network operations
USB Mouse Control
YES
Motion Detection Area
16 × 12 grids per channel
Motion Detection Sensitivity
3 adjustable parameters for accurate detection
Pre-alarm Recording
Backup Device
USB 2.0 flash drive / Network
Web Transmitting Compression Format
Ethernet
10/100 Base-T. Supports remote control and live view via Ethernet
Mobile Surveillance
YES (Including iPhone, BlackBerry, Windows Mobile, Symbian & Android)
Remote Surveillance
(Operating System:
Windows 7 / Vista / XP)
CMS:
Web Browser:
Our self-developed and free software,“Video Viewer”
Internet Explorer, Mozilla Firefox, Google Chrome &
Mac Safari
Media Player:
QuickTime
Max. on-line user:
5
Network Protocol
TCP/IP, PPPOE, DHCP and DDNS
Basic Remote Independent Operation
Event Notification
By FTP & E-Mail
Remote Event Download & Playback
IR Remote Control
YES (IR receiver built-in)
Picture Zoom
2X digital zoom
PTZ Control
Alarm I/O
8 inputs, 1 output
Key Lock (Password Protection)
User Level
Administrator & Operator
Video Loss Detection
Camera Title
Supports up to 12 letters
Video Adjustable
Hue / Saturation / Contrast / Brightness
Date Display Format
YY/MM/DD, DD/MM/YY & MM/DD/YY
Daylight Saving
Power Source (±10%)
DC 19V
Power Consumption (±10%)
＜64 W
Operating Temperature
10℃ ~ 40℃ (50℉~104℉)
Dimensions (mm)**
430(W) x 65(H) x 338(D)
System Recovery
System auto recovery after power failure
Optional Peripherals
Keyboard controller
